What good is a go-anywhere, ride-all-day, Bosch-powered bike without power? Not much, which is why every frame size of the Stereo Hybrid 140 HPC, right down to the smallest, accepts a 750Wh battery. Combined with up to 85Nm from the Bosch CX drive unit, it's your ticket to extended off-road adventures. The Boost 148 rear axle, large pivot bearings and All Mountain Geometry deliver assured handling, even when you're exploring the limits of the 140mm rear and 150mm front travel. Sram's UDH gear hanger helps protect against crash damage and is easily replaceable. And Internal Cable Routing reduces maintenance and complements the clean lines of the full carbon main frame. |
| Frame Material |
Battery |
| HPC |
750 Wh
|
Frame
|
Frame |
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Fully Integrated Battery, Advanced Internal Cable Routing |
| Size |
Size Split: 27.5: S // 29: M L XL |
Suspension
Suspension fork |
RockShox 35 Silver TK Air, Tapered, 15x110mm, eMTB Approved, 150mm, Lockout |
Shock |
RockShox Deluxe Select+, 205x60mm (27.5: 185x55mm), Rebound Adjust, Trunnion Mount, Lockout |
Shock hardware |
Top: 54mm Trunnion Mount, Bottom: 22.2x8mm |
E-bike system
| DRIVE UNIT | REMOTE | BATTERY | CHARGER |
 |
 |
 |
 |
|
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
|
Bosch LED Remote |
Bosch PowerTube 750 |
Bosch Kiox 300 |
Drivetrain & Brakes
Brake system |
Sram DB8, Hydr. Disc Brake (203/203) |
Rear derailleur |
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
Shifters |
Shimano Deore SL-M6100, Rapidfire-Plus |
Crankset |
ACID E-Crank, 165mm (27.5: 36T // 29: 34T) |
Cassette |
Shimano Deore CS-M6100, 10-51T |
Chain |
Shimano CN-M6100 |
Chain guide |
Reverse Flip-Guide E-Chain Guide, Direct Mount, GEN4 |
Cockpit
Headset |
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) |
Stem |
CUBE Performance Stem E-MTB, 31.8mm |
Handlebar |
Newmen Evolution SL 318.25, 760mm |
Grips |
ACID React Pro |
Wheels
Wheelset |
CUBE EX30, 32H, Disc, Tubeless Ready |
Front hub |
CUBE Engineered By Newmen, 15mm, Boost, Centerlock |
Rear hub |
CUBE Engineered By Newmen, 12mm, Boost, Centerlock |
Tyres |
Schwalbe Nobby Nic, PerfL, 2.6 |
Finishing Kit
Saddle |
Natural Fit Venec |
Seat post |
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
Product Information
Colour |
grey´n´chrome |
Weight |
24,8 kg |
